PSION 8088 laptops - MC line

I wonder if anyone uses PSION MC laptops? I mean the MC200/MC400 or the MC600.

The 200 and 400 use an early version of the SIBO system (it lacks some features of Series 3 operating system) and the MC600 uses the MS-DOS (3.3). They are actual laptops with full-size full-travel keyboard keys (the layout is a bit compromised, of course) and with 640x200 (640x400) passive black-white LCD screen (the MC200 has smaller display). I never measured it but think it’s about 9".

I personally use the MC600 for writing PSION Organiser II software in OPL (there is an IDE with emulator for MS-DOS!), to sync data with the Organiser II and for other tasks (reading ot TXT files, writing, some light computing and so on).

These machines can run on 8xAA batteries and are perfectly happy with modern rechargeables. Can survive months ins sleep and 40+ hours of active work. They have no HDD - they use PSION SSD disks (up to 4) instead. So the same media as Series 3 use. There are same limitations of SSD size - flash-based msut be Type I and no larger than 1MB, RAM-based can be of any size (though finding a 2MB third-party RAM SDD is quite hard - I have only one). The device has usually 1 serial (mac-type connector) and 1 parallel port. These port are in an removable module and (in theory) one can se 2 of those modules.

The MC600 can communicate with the Atari Portfolio on the parallel port, by the way.

I can say less about the SIBO-based MC400. If is even nicer (GUI interface similar to later Series 3 interface, large touchpad etc). Some Series 3 applications have version compatible with the MC (for example the dictionary) but software for this device is not common. There is a text editor, an OPL interpreter, a serial communication program and not much more (an alarm clock, a calendar and a calculator). The word processor (RTF-capable) and a spreadsheet (can do Lotus123 files) were sold separely. They are quite basic (no graphs in spreadsheed, for example) but easy to use. An then there is not much more. The OPL interpreter cannot use any GUI or graphical elements (one cannot draw even simple line).

1 Like

Interesting - I’m not sure these slightly later Psions even came up on my radar, which is a bit surprising. (So, as you might guess, I’ve never used one.)

(For earlier psions, see this earlier thread: The Psion HC - in between the 1 and the 3 (?) and maybe MalayBook: Special version of the Psion netBook produced for schools in Malaysia)

1 Like

These two are mine! :grinning:

4 Likes

That’s marvellous! From what you say, I think the MC400 is my instant favourite - nice screen compared to the 200, and still pre-DOS unlike the 600. How do the keyboards compare to the Series 3?

They are much like average PC keyboards of their days (~1988). Thus much better than Series 3 tiny keyboards.

If I remember correctly the early Apple PowerBooks (which are of similar size) had much worse keyboards.

1 Like

Disclaimer: long-time Psion fanboy :slight_smile:

I briefly owned an MC400 in the 1990s and I’ve regretted selling it ever since. After a loft/attic clearout in 2020 I rediscovered some of my old Psion collection I started looking on eBay for MC400s… now I have 3!

I’ve hooked one of them up to “the internet” via a Raspberry Pi (what else? :slight_smile: ) and/or NodeMCU see here - I even wrote some OPL to compose tweets/email from the MC400 too

One of the 3 is in really poor state of repair as is has some serious leaked NiCd damage to the main PCB… this has to be the best candidate for a Pi-transplant, or possibly just donate the keyboard (with matrix/USB adapter of course) for some good old mechanical keyboard vibes :wink:

The latest one I found on eBay is very interesting - basically a stripped down “MC WORD” version with OEM OPL to create a remote text processing and transmission terminal for journalists to submit stories back to a central news desk. Created as a direct competitor/replacement for the Tandy TRS-80 200 - link

3 Likes

The user interface is intriguing. I’m getting more interested in the PDA lineage of user interfaces as time goes on.

I wondered if the MC400 was available from an online retailer I am aware of. Sure enough, it is:

If you have to ask the price then maybe you can’t afford it. :wink:

1 Like

The price disappeared after I bought the MC600 from the Pulster… I seemed to me that it was the last one available…

I still enjoying using it. But it is the DOS model (without the GUI).

3 Likes

davidb

For that reason I’d love to see an MC400 emulator :wink: The user interface is clean and simple and I would love to see it preserved for posterity in some sort of emulation environment.

I’ve imaged the ROM of one of my dead machines… :thinking:

1 Like

Edit: Ah, I see you’ve already started! I didn’t see initially that the post below is yours…

I found an interesting recent post about an adventure which may yet bear fruit:

1 Like

Yeah, that’s me - I’ve started but my skills run out at:

:wink:

I have the ROM image, I have the HDK/SDK from Alex Brown’s Psion Documentation Project (via his Hackaday page “The Last Psion”) and that’s about it :-d

And by the way, these machine do not use the 8088 as the title suggests. In common with the Series 3/3a, HC & Workabout ranges they utilise the 80C86.

1 Like

Looks like an emulator might be starting to come together - watch the action over on stardot with Pernod and @zedstarr finding their way…

1 Like

Looked promising:

MC400_V2.60F_boot_splash_0001

but brick wall now hit with lack of documentation for the custom ASICs :frowning:

I’m contemplating whether it’s worth trying twitter/LinkedIn/Facebook groups to see if any ex-Psion/Symbian engineers can help. But it’s ~30 years ago this stuff was current :thinking:

3 Likes

This is great!

I think it might worth to try…

Perhaps slightly OT, but as I’d somehow missed that the MC line was a precursor to the whole palmtop adventure, as penance I offer this history:
3-Lib History of Psion

3 Likes

I remember picking up a glossy promotional brochure for the MC line - it was A4 sized and when you opened it up it looked just like the MC400, full-page pictures of the screen on the left page/keyboard on the right. This must have been 1989/1990 ish. I was instantly hooked :smiley: At that time having a truly portable computer this size blew me away! I’d used “luggable” PCs at work (something like this luggable Compaq 386 ) and knew smaller was better :slight_smile:

1 Like

Finally got round to re-purposing the keyboard from the dead MC400 as a USB keyboard - thanks to Frank Adams’ Teensy LC sketch I worked out the matrix and managed to hack it around into actually working as a USB keyboard :wink: [Apologies for the slow one-handed typing - not easy when holding the phone in the other hand :smiley: ]

My Teensy LC code is here

4 Likes

A little more progress:
0005
